Audiocenter Single 10” Active Speaker

DESCRIPTION	SPECIFICATION
Type	Active DSP-controlled full range loudspeaker
Frequency Response (-6dB anechoic chamber)	57Hz-20KHz
Maximum Calculated SPL/1M	130dB
LF Driver	Customized AUDIOCENTER ferrite driver, 2” voice coil
HF Driver	Customized AUDIOCENTER ferrite driver, 1 exit, 1.75” voice coil
Horizontal Coverage Angle (Symmetrical)	90°
Vertical Coverage Angle (Symmetrical)	60°
Amplifier Circuitry	Class D
Power (Peak)	2000W
Frequency Response (1W 8Ω 2ch)	20Hz-20KHz (±0.5dB)
Intermodulation Distortion	< 0.05%
Total Harmonic Distortion	< 0.05%
Protection	DC Protection, short circuit protection, overheat protection, input overload protection, output overload protection, soft startup protection, overvoltage protection, under voltage protection.
Cooling System	Cooling with fans, air convection
Processor	96KHz signal sampling frequency, 24bit precision
Presets	Adjustable via the knobs on the back panel
Crossover	Controlled by DSP
Signal Input	1x NEUTRIK® female XLR, Mono jack 6.35, 1xRCA, 1x Wireless Bluetooth
Signal Output	1x NEUTRIK® male XLR
Power Input	3 pin plug
Working Voltage	100v-130v/60Hz or 220v-240v/50Hz
Cabinet Material	CNC made
Cabinet Color	Black standard color
Dimension (W x H x D)	296 × 530 × 312mm
Net Weight	14.5Kg
